Qrisp

The next generation of quantum algorithm development

Qrisp is a high-level programming language for creating and compiling quantum algorithms. Its structured programming model enables scalable development and maintenance.

Explore parametrized algorithms with symbolic statevector simulation

\[ \begin{align}\begin{aligned}\definecolor{qrispblue}{RGB}{32, 48, 111} \definecolor{textgray}{RGB}{68, 68, 68}\\\Large \textcolor{textgray}{ \begin{align} \frac{\ket{\texttt{hello}} + e^{i \textcolor{red}{\phi}} \ket{\texttt{world}}}{\sqrt{2}} \end{align} }\end{aligned}\end{align} \]



Key Features#

_images/typed_variables_pic.png

Typed quantum variables
Qrisp algorithms are constituted of variables and functions instead of qubits and circuits, which helps you to structure your code and avoid technical debt.

_images/recycling.png

Automatic uncomputation
QuantumVariables can be uncomputed automatically once they are not needed anymore. The uncomputation module is tightly integrated with an advanced qubit resource management system.

_images/puzzle.png

Modularity
Automated qubit allocation allows separate modules to recycle qubit resources for each other without intertwining the code. This feature facilitates interoperability of code written by respective domain experts.

_images/abakus.png

Arithmetic
A smoothly integrated system of floating point arithmetic streamlines the development of non-trivial applications.

_images/plug.png

Compatibility
Compilation results are circuit objects, implying they can be run on a variety of hardware providers such as IBM Quantum, Quantinuum, Rigetti etc. Further circuit processing is possible using circuit optimizers like PyZX.

_images/quantumcomputer.png

Simulator
Qrisp ships with a high-performance simulator, that utilizes sparse matrices to store and process quantum states. This allows for the simulation of (some) quantum circuits involving 100+ qubits.

Dive into Qrisp code#

Qrisp code can be significantly shorter and also more readable than the equivalent program in a gate based framework. Regardless, the compiled quantum circuits are in many cases more efficient since the compiler can leverage the code structure into assumptions about algorithmic structure, implying strong compilation optimizations. Below you find two code snippets that perform the same basic task: Multiplication of two n-bit integers. One is written using Qiskit and the other one utilizes Qrisp.

Qrisp Logo Qiskit Logo
from qiskit import (QuantumCircuit, QuantumRegister,
ClassicalRegister, transpile)
from qiskit_aer import Aer
from qiskit.circuit.library import RGQFTMultiplier
n = 6
a = QuantumRegister(n)
b = QuantumRegister(n)
res = QuantumRegister(2*n)
cl_res = ClassicalRegister(2*n)
qc = QuantumCircuit(a, b, res, cl_res)
for i in range(len(a)):
        if 3 & 1<<i: qc.x(a[i])
for i in range(len(b)):
        if 4 & 1<<i: qc.x(b[i])
qc.append(RGQFTMultiplier(n, 2*n),
list(a) + list(b) + list(res))
qc.measure(res, cl_res)
backend = Aer.get_backend('qasm_simulator')
qc = transpile(qc, backend)
counts_dic = backend.run(qc).result().get_counts()
print({int(k, 2) : v for k, v in counts_dic.items()})
#Yields: {12: 1024}
from qrisp import QuantumFloat
n = 6
a = QuantumFloat(n)
b = QuantumFloat(n)
a[:] = 3
b[:] = 4
res = a*b
print(res)
#Yields: {12: 1.0}

Apart from simple scripts like the above, our tutorial showcases the utilization of Qrisp implementing Shor’s algorithm leveraging Montgomery reduction, fully agnostic to the particular quantum adder. This solution involves several conceptually distinct QuantumVariables, with their respective qubits being repeatedly disentangled and repurposed for other variables. The presented approach improves the resource requirement of known open source implementations significantly, while retaining an accesible form.

This example illustrates how Qrisp, as a high-level language, permits novel and scalable solutions to intricate problems and furthermore that high-level quantum programming languages will be an integral part of the future of quantum information science.

Who is behind Qrisp#

Qrisp is an Eclipse open-source project developed mainly at Fraunhofer FOKUS, an industrial research facility based in Berlin. It is publicly funded by the German ministry of economic affairs and the European Union with the aim to enable commercial use of quantum computation. To achieve this, we aim to open this field of research to a broad audience of developers. Furthermore we are proud to announce that Qrisp will become a part of the Eclipse foundation!
